MAIN CHARACTERISTICS

Bucket Capacity: 0.022m³
Engine Power: 7.2kW/2400rpm
Operating Weight: 1.1t

FEATURES

Strong power system and high reliability
•Pilot-operated

Beautiful appearance
•Using the appearance designed by internationally renowned modeling company, dynamic and fashionable appearance, small vibration noise, and in line with ergonomics.

Working range
•Tailless slewing, able to work in narrow space.

TECHNICAL PARAMETERS

Dimension (L×W×H): 2930 x 750 x 2130 mm
A Max. Digging Height: 3092  mm
B Max. Loading Height: 2314 mm
C Max. Digging Depth: 1813 mm
D Max. Vertical Wall Digging Depth: 1430 mm
E Max. Digging Reach: 3343 mm
F Max. Digging Reach at Ground Level: 3243 mm
G Max. Lifting Height of Blade: 225 mm
H Max. Digging Depth of Blade: 225 mm
R Min. Swing Radius: 1395 mm

Length & width of Blade: 1000*197 mm
Overall Weight Rubber Track: 1.1t
Standard Bucket Capacity: 0.022 m³
Bucket Digging Force: 9.4 kN
Stick Digging Force: 5.8 kN
Max. Traction: 9.4 kN
Power: 7.2/2400 kW/rpm
Swing Speed: 8.2 rpm
